🤖 DeepMCPAgent

flowchart LR
    %% Groupings
    subgraph User["👤 User / App"]
      Q["Prompt / Task"]
      CLI["CLI (Typer)"]
      PY["Python API"]
    end

    subgraph Agent["🤖 Agent Runtime"]
      DIR["build_deep_agent()"]
      PROMPT["prompt.py\n(DEFAULT_SYSTEM_PROMPT)"]
      subgraph AGRT["Agent Graph"]
        DA["DeepAgents loop\n(if installed)"]
        REACT["LangGraph ReAct\n(fallback)"]
      end
      LLM["LangChain Model\n(instance or init_chat_model(provider-id))"]
      TOOLS["LangChain Tools\n(BaseTool[])"]
    end

    subgraph MCP["🧰 Tooling Layer (MCP)"]
      LOADER["MCPToolLoader\n(JSON-Schema ➜ Pydantic ➜ BaseTool)"]
      TOOLWRAP["_FastMCPTool\n(async _arun → client.call_tool)"]
    end

    subgraph FMCP["🌐 FastMCP Client"]
      CFG["servers_to_mcp_config()\n(mcpServers dict)"]
      MULTI["FastMCPMulti\n(fastmcp.Client)"]
    end

    subgraph SRV["🛠 MCP Servers (HTTP/SSE)"]
      S1["Server A\n(e.g., math)"]
      S2["Server B\n(e.g., search)"]
      S3["Server C\n(e.g., github)"]
    end

    %% Edges
    Q -->|query| CLI
    Q -->|query| PY
    CLI --> DIR
    PY --> DIR

    DIR --> PROMPT
    DIR --> LLM
    DIR --> LOADER
    DIR --> AGRT

    LOADER --> MULTI
    CFG --> MULTI
    MULTI -->|list_tools| SRV
    LOADER --> TOOLS
    TOOLS --> AGRT

    AGRT <-->|messages| LLM
    AGRT -->|tool calls| TOOLWRAP
    TOOLWRAP --> MULTI
    MULTI -->|call_tool| SRV

    SRV -->|tool result| MULTI --> TOOLWRAP --> AGRT -->|final answer| CLI
    AGRT -->|final answer| PY

sequenceDiagram
    autonumber
    participant U as User
    participant CLI as CLI/Python
    participant Builder as build_deep_agent()
    participant Loader as MCPToolLoader
    participant Graph as Agent Graph (DeepAgents or ReAct)
    participant LLM as LangChain Model
    participant Tool as _FastMCPTool
    participant FMCP as FastMCP Client
    participant S as MCP Server (HTTP/SSE)

    U->>CLI: Enter prompt
    CLI->>Builder: build_deep_agent(servers, model, instructions?)
    Builder->>Loader: get_all_tools()
    Loader->>FMCP: list_tools()
    FMCP->>S: HTTP(S)/SSE list_tools
    S-->>FMCP: tools + JSON-Schema
    FMCP-->>Loader: tool specs
    Loader-->>Builder: BaseTool[]
    Builder-->>CLI: (Graph, Loader)

    U->>Graph: ainvoke({messages:[user prompt]})
    Graph->>LLM: Reason over system + messages + tool descriptions
    LLM-->>Graph: Tool call (e.g., add(a=3,b=5))
    Graph->>Tool: _arun(a=3,b=5)
    Tool->>FMCP: call_tool("add", {a:3,b:5})
    FMCP->>S: POST /mcp tools.call("add", {...})
    S-->>FMCP: result { data: 8 }
    FMCP-->>Tool: result
    Tool-->>Graph: ToolMessage(content=8)

    Graph->>LLM: Continue with observations
    LLM-->>Graph: Final response "(3 + 5) * 7 = 56"
    Graph-->>CLI: messages (incl. final LLM answer)

stateDiagram-v2
    [*] --> AcquireTools
    AcquireTools: Discover MCP tools via FastMCP\n(JSON-Schema ➜ Pydantic ➜ BaseTool)
    AcquireTools --> Plan

    Plan: LLM plans next step\n(uses system prompt + tool descriptions)
    Plan --> CallTool: if tool needed
    Plan --> Respond: if direct answer sufficient

    CallTool: _FastMCPTool._arun\n→ client.call_tool(name, args)
    CallTool --> Observe: receive tool result
    Observe: Parse result payload (data/text/content)
    Observe --> Decide

    Decide: More tools needed?
    Decide --> Plan: yes
    Decide --> Respond: no

    Respond: LLM crafts final message
    Respond --> [*]

classDiagram
    class StdioServerSpec {
      +command: str
      +args: List[str]
      +env: Dict[str,str]
      +cwd: Optional[str]
      +keep_alive: bool
    }

    class HTTPServerSpec {
      +url: str
      +transport: Literal["http","streamable-http","sse"]
      +headers: Dict[str,str]
      +auth: Optional[str]
    }

    class FastMCPMulti {
      -_client: fastmcp.Client
      +client(): Client
    }

    class MCPToolLoader {
      -_multi: FastMCPMulti
      +get_all_tools(): List[BaseTool]
      +list_tool_info(): List[ToolInfo]
    }

    class _FastMCPTool {
      +name: str
      +description: str
      +args_schema: Type[BaseModel]
      -_tool_name: str
      -_client: Any
      +_arun(**kwargs) async
    }

    class ToolInfo {
      +server_guess: str
      +name: str
      +description: str
      +input_schema: Dict[str,Any]
    }

    class build_deep_agent {
      +servers: Mapping[str,ServerSpec]
      +model: ModelLike
      +instructions?: str
      +returns: (graph, loader)
    }

    StdioServerSpec <|-- ServerSpec
    HTTPServerSpec <|-- ServerSpec
    FastMCPMulti o--> ServerSpec : uses servers_to_mcp_config()
    MCPToolLoader o--> FastMCPMulti
    MCPToolLoader --> _FastMCPTool : creates
    _FastMCPTool ..> BaseTool
    build_deep_agent --> MCPToolLoader : discovery
    build_deep_agent --> _FastMCPTool : tools for agent
